UMPC - Flybook V23i (C600) HSDPA
The product from the archive - production terminated
OVERVIEW
|
|
MOBILITY WITH NO COMPROMISE
Its modest dimensions and weight (23,5x15,5 x3,1(cms for 1.2 kgs) make Flybook V23 a highly portable notebook that suits any occasion. The thorough study of all the ergonomic aspects, the keyboard dimensions and the position of the main control keys allow a very simple usage – even standing.
|
|
TOTAL CONNECTIVITY
Connected everywhere: your Flybook V23 allows you to stay always connected thanks to its in-built technologies. Data, videos and voice (optional) can be transferred and received both wired and wireless using high-speed connections. |
 |
|
Flybook V23 integrates the latest communication technologies, wired and wireless. |
 |
WIRELESS WAN CONNECTIVITY
(cellular network)
Thanks to the in-built HSDPA module, you need only to insert a SIM card in the special slot, and you will immediately be able to easily connect to the Internet. The integrated software is able to automatically recognise and customise all network providers worldwide. And the study of the antennae localisation allows a receiving capacity unreachable by the external USB or PCMCIA transmission devices. Besides, it allows you to reach the highest connection speeds even in poor network conditions.
|
|
WIRELESS LAN CONNECTIVITY
The great expansion of WiFi technologies to wireless connect to the Internet both in professional and domestic settings through the public or private hot-spots, make your Flybook V23 an inseparable resource for your daily activities. |
 |
 |
BLUETOOTH CONNECTIVITY
No more cable connections! Thanks to the bluetooth technology that allows the exchange of information among different devices, you can easily use all the accessories of the Flybook line (and more) with an in-built special software. |
|
CABLE CONNECTIVITY
(LAN / modem)
Equipped with the latest Gigabit LAN technology, your Flybook V23 reaches the top af all performances when it comes to LAN networks. By inserting the Ethernet cable, the system immediately recognises the specific connection used and allows you to transfer data at extremely high speeds. And besides having all the latest technologies, your Flybook V23 has an in-built 56K analogic modem that can connect to a traditional telephone line when necessary. |
 |
|
IMEI CODE
The Flybook’s integrated cellular system allows the topmost security level. In case of theft, its IMEI code (International Mobile Equipment Identity) allows the immediate localisation of your computer, speeding up the work of police forces in helping you having your notebook back. |
|
|
TOUCH SCREEN
Use your Flybook V23 like a real block notes: thanks to its touch-panel, it allows you to write your notes on the screen as you would do with a normal paper sheet. The stylus pen can be used to easily and quickly access all the Flybook’s functions or to add notes to your documents. Thanks to the Microsoft Windows Vista operative system, it’s easier to manage all the info written on the screen: use the tools given by the O.S. and see how they perfectly integrate with Flybook’s technology. |
|
|
|
|
While you are away on a business trip settled in your hotel room, you no longer need to worry about your connections. Flybook will connect you to the wireless network and through the HSDPA system you’ll be able to download your e-mails in the comfort of your hotel room’s bed. Thanks to its connective technology, Flybook will also allow you to make personal or business phone calls worldwide via the web at no extra costs!
As you drift away through the sea of entertainment, you’ll always have at your service your inseparable number one tool: Flybook. Thanks to its GPS Bluetooth antenna and its positioning satellite system, you’ll be able to receive any and all kinds of helpful information as well as pursue your route on its touch-screen display. |
|
| The office in your pocket |
|
Live in freedom with Flybook. Choose unlimited connectivity and open your mobile office whenever and wherever you are. Anywhere and at anytime - in the park while you’re laying down on the grass listening to you favourite type of music or even in the centre of town connected via a public wireless hotspot, Flybook will always be ready to assist you!
| Waiting couldn’t be better! |
|
The concept of idling away the hours at the departure lounge or in between flights is soon to be changed as you discover the world of Flybook. Watching a film in digital format, listening to music, watching the news via internet or even reading e-mails, checking-up your appointments, getting down to work is something you’ll now look forward to during your waiting hours!
Flybook won’t let you waist not even one single second of your time. Even the train can become your perfect office. Flybook is connectivity at all times through the world of wireless network via the HSDPA system with unlimited possibilities as to what you can accomplish with its help. Enhanced with Microsoft Windows Office XP®, as well as all of its other functional pre-installed programs, Flybook is your world of opportunities. |
VIDEO
Flybook V23i
| WAN: |
HSDPA/UMTS/EDGE/GPRS/GSM (data and SMS). UMTS (HSDPA): 850/1900 i 2100 MHz, EDGE/GPRS/GSM: 850/900/1800/1900. |
| WLAN: |
IEEE 802.11 b/g |
| Bluetooth: |
Bluetooth 1.2 |
| Processor: |
Intel Celeron Mobile 600 MHz |
| Memory: |
1GB DDR2 (up to 2GB) |
| Chipset: |
ATI RS450 |
| Dispaly: |
8.9'' WSVGA TFT (1024x600) LCD (16:9) |
| Graphics card: |
ATI RADEON XPRESS 200 M (128MB) |
| Touch screen: |
Yes |
| Swivel Hinge: |
Yes |
| Hard Drive: |
2.5'' 60 GB (max 300GB) |
| BIOS: |
Phoenix FB |
| VGA out: |
Yes (D-sub 15pin). Up to 1800 x 1440 resolution (highest to 32-bit color) |
| LAN: |
10/100Mbps & Gigabit LAN |
| Camera: |
No |
| Audio: |
AC 97 - two stereo speakers |
| Seciurity: |
Kensington lock |
| TV Out: |
NTSC/PAL |
| In/Out: |
1 x Modem V.92 (RJ-11), 1 x LAN (RJ-45), 1 x headphones out, 1 x microphone out, 2 x USB 2.0, 1 x PCMCIA, 2 x FireWire, 1 x mini-VGA, 1 x TVout |
| Keyboard: |
QWERTY + function keys |
| Additional Navigation Devices : |
Mouse buttons(R/C/L), Trackpoint, Shift Control, Right Button enable, Other quick-key on keyboard |
| Battery: |
Battery 3-cell Li-Ion (2400mAh) |
| Working time on battery: |
Standard battery - up to 3 hours. BIG (doubble battery) - up to 5 hours 15 minutes |
| Size: |
235 x 155 x 31 (mm) / weight 1230 g |
| CD/DVD: |
No (Optional YES - external - through USB) |
| Operating System: |
Microsoft Windows XP Home |
| Flash Card Reader: |
No |
| GPS: |
No (Optional Yes Bluetooth or USB module) |
| TV Tuner: |
No |
| Color: |
Matt - Black / Red |
|
