Industrial data collector CILICO CM388-2D Newland

e-mail: sklep@mobilator.pl
phone: +48 508-235-505

www.mobilator.pl/przemyslowy-kolektor-danych-cilico-cm388-2d-newland-produkt-87606.html

Industrial data collector CILICO CM388-2D Newland

telefon wytrzymały ip65 3g rfid kolektory danych

Description
Resistance
The collection and processing of data
Modules and Wireless Networks
Minimalism

CM388 adopts the combination of platformization and modular function design concept. It not only has intelligent operation platform, but also has modular functions with flexible configuration. So it can satisfy the customized requirements from different customer.

Description

telefon wytrzymały ip65 3g rfid kolektory danych cilico cm388

Processor	Qualcomm MSM8625Q (Quad Core 4x - 1.2GHz)
Graphics	Andreno 203
Display	3.8" (480x800) LCD
Type of display	Capacitive
RAM	1GB
ROM	4GB
Connectors (factory)	MicroUSB (OTG) \| MicroSD \| Slot SIM \| Audio Jack
GPS (factory)	GPS + A-GPS
Audio	Built-in Microphone \| Receiver \| Audio Jack
Camera (Rear)	5Mpx (Autofocus + LED)
Keyboard	On-Screen + Alfphanumeric
	Menu \| Home \| Return \| Search \| ON/OFF
	1x - Left button calling the scanner
	1x - Right button calling the scanner
	1x- Volume +
	1x - Volume -
Battery	Li-Ion 3.7V 4000mAh
	Standby mode - 72h
	Operating mode (depending on usage) - 6h
System	Android 4.1.2
Modules (factory)	802.11 b/g/n \| Bluetooth v4.0 \| 2G/3G \| GPS \| NFC
Modules (optional)	(1D) Mindeo UE966 \| (1D/2D) Newland EM3095 \| (1D/2D) Motorola SE4500
Dimensions	135 x 69 x 16 mm \| 176g (with battery)
Resistance	IP65
Sensors (factory)	G-Sensor \| Distance Sensor \| Light Sensor \| E-Compass
Warranty	12 months

Refer to the "Technical Data" that possibility is a version of the device. To gain additional information about the product click on the "Request for information" or go to the contact form.

Version for you

Refer to the "Technical Data" overlap - what possibility have subsequent versions of the devices. To gain additional information about the product click on the "Ask about the product" or go to the contact form.

	1D	2D Newland	2D Motorola
1D (LASER) Mindeo UE966		-
1D/2D (CMOS) Newland EM3095	-		-
1D/2D (BI-DIR) Motorola SE4500	-	-

go top… menu…

Resistance

Gorilla Glass

More and more manufacturers in their production reaches the glass, which is to protect the screen from scratches, cracks or zgnieceniami. The best material on the market today that meets these requirements, it is Gorilla Glass. The use of this technology in the recent product of CILICO guarantees operation for many years.
telefon gorilla glass przemysłowy kolektor danych

Operating	-10°C -- +60°C
Storage	-20°C -- +65°C
Relative Humidity	5% - 90% bez kondensacji
Dust	IP6x (dust)
Water	IPx5 (water)
Drop	1.2m

Resistance

IP stands for Ingress Protection and is essentially a rating system developed by the International Electrotechnical Commission or the IEC. The system is now being used to classify different degrees of protection against intrusion or immersion. The IP rating is usually followed by two digits. The first indicates the level of dust-resistance, the second water resistance. Dust-resistance levels goes from 0 up to 6 while water-resistance goes from 0 to 8.

Complete protectionm against contact, Protection from infiltration of dust.

Protection from water projected from a nozzle.

go top… menu…

The collection and processing of data

Barcode Scanner

Barcode Reader allows you to read, decode and transfer stored data in barcode to your computer. Thanks to dynamic scanning method and the large range of reading, data collector is capable to carefully collecting data, which helps to increase the rate and efficiency of work. Simplified installation procedure, convenient and intuitive design allow to start scanner work very easy and quickly.

1D	1D / 2D
MINDEO™ UE966 (LASER)	NEWLAND™ EM3095 (CMOS)
	MOTOROLA™ SE4500 (BI-DIRECTIONAL)

NFC

Near field communication (NFC) is a set of ideas and technology that enables smartphones and other devices to establish radio communication with each other by touching the devices together or bringing them into proximity to a distance of typically 10 cm (3.9 in) or less.

cilico cm388 NFC

Type	NFC
Frequency	13.56 MHz
Standard	ISO/IEC 15693
	ISO/IEC 14443 A/B

kolektor danych cilico cm388

go top… menu…

Modules and Wireless Networks

With 3G module, you need only insert a SIM card into a special slot and can immediately connect to the Internet. Integrated software allows you to automatically recognize and customize mobile networks. Also used in internal CM388 WCDMA module adapts automatically to transfer and network coverage.

WIFI	802.11 a/b/g/n
GPS (Standard)	GPS + A-GPS
Bluetooth	Bluetooth v4.0
2G/3G	GSM/GPRS/EDGE: 850/900/1800/1900 Mhz
	WCDMA 2100MHz \| EVDO 800MHz/CDMA2000
	The ability to make voice calls

gps cilico cm388

The latest WiFi wireless module operating in 802.11n provides a very fast and secure communication with the AP tablet such as a router, providing a fast and convenient web browsing, smooth playback of HD video.

go top… menu…

Minimalism

Compactness

CM388 weighs only 200g and its dimensions (135 x 69 x 16mm) allow you to take it with them everywhere. With sleek performance and energy efficiency is on the forefront of devices in this segment and enjoys great popularity on the Polish market in the industrial segment.

telefon ip65 kolektor danych android rfid barcode scanner gorilla glass

Dimensions	135 x 69 x 16 mm
Weight	176g (with battery)

gorilla glass telefon cilico cm380 kolektory danych rfid barcodescanner android

go top… menu…

more photos in the "Photo Gallery" ...

specification of this version is available in the "Technical data" ...

Operating System:	Android 4.1.2
Dispaly:	3.8" (480x800) LCD
Brightness:	-----
Processor:	Qualcomm MSM8625Q (Quad Core 4x - 1.2GHz)
Memory:	1GB
Hard Drive:	4GB
Flash Memory:
Touch screen:	Yes - capacitive
Durability:	IP65
Drop:	1.2 meters
Shock:	-----
Vibration:	-----
Temperature:	Operating temperature: -10°C -- +60°C Storage temperature: -20°C -- +65°C
Humidity:	5% - 90% non-condensing
1D barcode scanner (reader):	(2D) NEWLAND™ EM3095 (CMOS)
2D barcode scanner (reader):	(2D) NEWLAND™ EM3095 (CMOS)
RFID scanner (reader):	none (available in other configurations)
Other:	-----
Battery:	Li-Ion 3.7V 4000mAh
Working time on battery:	Operating time (depending on usage) - 6h Standby time - 72h
Fast battery replacement ability:	Yes
HotSwap battery:	No
LAN:	-----
WLAN:	IEEE 802.11b/g/n
Bluetooth:	Bluetooth v4.0
WAN:	2G: GSM/GPRS/EDGE: 850/900/1800/1900 Mhz 3G:WCDMA 2100MHz \| EVDO 800MHz/CDMA2000
GPS:	GPS + A-GPS
Camera:	REAR: 5MPX (Auto Focus+ Flash)
In/Out:	MicroUSB (OTG) \| MicroSD \| Slot SIM \| Audio Jack
Optional accessories:	-----
Docking station connector:	-----
VESA standard – holders and mounts support:	-----
COM port:	No
Magnetic card reader (MSR):	-----
Microchip card reader:	-----
Contrast:	-----
Graphics card:	Andreno 203
Chipset:	-----
BIOS:	-----
Casing material:	high quality plastic and rubber
Flash Card Reader:	Yes - max. 32GB
CD/DVD:	-----
Audio:	Built-in Microphone \| Receiver \| Audio Jack
Keyboard:	On-Screen + Alfphanumeric Home \| Menu \| Return \| ON/OFF 2x - calling the scanner 1x- Volume - 1x - Volume +
Additional Navigation Devices :	-----
Color:	czarno-złoty
Swivel Hinge:	-----
VGA out:	-----
TV Out:	-----
TV Tuner:	-----
Seciurity:	IP65
Waterproof:	IPx5
Sand and dust:	IP6x
Size:	135 x 69 x 16 mm 176g
Fanless casing:	Yes
Weight:

CURRENT PRICE
537.11 €	Net
660.65€	Gross
